证书common name

1
2
3
4
5
6
7
8
9

# openssl req -x509 -newkey rsa:4096 -keyout key.pem -out cert.pem -sha256 -days 3650 -nodes -subj
"/C=XX/ST=StateName/L=CityName/O=CompanyName/OU=CompanySectionName/CN=01234567890123456789012345678901234567890123456789012345678901234"
Generating a RSA private key
........................++++
........................................++++
writing new private key to 'key.pem'
-----
problems making Certificate Request
140059529942848:error:0D07A097:asn1 encoding routines:ASN1_mbstring_ncopy:string too long:crypto/asn1/a_mbstr.c:107:maxsize=64

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14

-- Naming attributes of type X520CommonName

id-at-commonName        AttributeType ::= { id-at 3 }

-- Naming attributes of type X520CommonName:
-- X520CommonName ::= DirectoryName (SIZE (1..ub-common-name))
--
-- Expanded to avoid parameterized type:
X520CommonName ::= CHOICE {
      teletexString     TeletexString   (SIZE (1..ub-common-name)),
      printableString   PrintableString (SIZE (1..ub-common-name)),
      universalString   UniversalString (SIZE (1..ub-common-name)),
      utf8String        UTF8String      (SIZE (1..ub-common-name)),
      bmpString         BMPString       (SIZE (1..ub-common-name)) }

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42

-- specifications of Upper Bounds MUST be regarded as mandatory
-- from Annex B of ITU-T X.411 Reference Definition of MTS Parameter
-- Upper Bounds

-- Upper Bounds
ub-name INTEGER ::= 32768
ub-common-name INTEGER ::= 64
ub-locality-name INTEGER ::= 128
ub-state-name INTEGER ::= 128
ub-organization-name INTEGER ::= 64
ub-organizational-unit-name INTEGER ::= 64
ub-title INTEGER ::= 64
ub-serial-number INTEGER ::= 64
ub-match INTEGER ::= 128
ub-emailaddress-length INTEGER ::= 255
ub-common-name-length INTEGER ::= 64
ub-country-name-alpha-length INTEGER ::= 2
ub-country-name-numeric-length INTEGER ::= 3
ub-domain-defined-attributes INTEGER ::= 4
ub-domain-defined-attribute-type-length INTEGER ::= 8
ub-domain-defined-attribute-value-length INTEGER ::= 128
ub-domain-name-length INTEGER ::= 16
ub-extension-attributes INTEGER ::= 256
ub-e163-4-number-length INTEGER ::= 15
ub-e163-4-sub-address-length INTEGER ::= 40
ub-generation-qualifier-length INTEGER ::= 3
ub-given-name-length INTEGER ::= 16
ub-initials-length INTEGER ::= 5
ub-integer-options INTEGER ::= 256
ub-numeric-user-id-length INTEGER ::= 32
ub-organization-name-length INTEGER ::= 64
ub-organizational-unit-name-length INTEGER ::= 32
ub-organizational-units INTEGER ::= 4
ub-pds-name-length INTEGER ::= 16
ub-pds-parameter-length INTEGER ::= 30
ub-pds-physical-address-lines INTEGER ::= 6
ub-postal-code-length INTEGER ::= 16
ub-pseudonym INTEGER ::= 128
ub-surname-length INTEGER ::= 40
ub-terminal-id-length INTEGER ::= 24
ub-unformatted-address-length INTEGER ::= 180
ub-x121-address-length INTEGER ::= 16

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25

/* size limits: this stuff is taken straight from RFC3280 */

#define ub_name                         32768
#define ub_common_name                  64
#define ub_locality_name                128
#define ub_state_name                   128
#define ub_organization_name            64
#define ub_organization_unit_name       64
#define ub_title                        64
#define ub_email_address                128
#define ub_serial_number                64

/* From RFC4524 */

#define ub_rfc822_mailbox               256

/* This table must be kept in NID order */

static const ASN1_STRING_TABLE tbl_standard[] = {
    {NID_commonName, 1, ub_common_name, DIRSTRING_TYPE, 0},
    {NID_countryName, 2, 2, B_ASN1_PRINTABLESTRING, STABLE_NO_MASK},
    {NID_localityName, 1, ub_locality_name, DIRSTRING_TYPE, 0},
    {NID_stateOrProvinceName, 1, ub_state_name, DIRSTRING_TYPE, 0},
    {NID_organizationName, 1, ub_organization_name, DIRSTRING_TYPE, 0},
。。。。

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15

main()
  |
  └──> do_cmd()
        |
        └──> req_main()
              |
              └──> X509_REQ_new()
              |
              └──> X509_REQ_set_subject_name()
                    |
                    └──> X509_NAME_add_entry_by_txt()
                          |
                          └──> ASN1_mbstring_copy()
                                |
                                └──> ASN1_mbstring_ncopy()
